DHN Disc Fat Milk Centrifuge Separator

DHN Disc Fat Milk Centrifuge Separator
DHN Disc Fat Milk Centrifuge Separator DHN Disc Fat Milk Centrifuge Separator DHN Disc Fat Milk Centrifuge Separator DHN Disc Fat Milk Centrifuge Separator

Large Image :  DHN Disc Fat Milk Centrifuge Separator

Product Details:
Place of Origin: Jiangsu, China
Brand Name: Juneng
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $26,987-30,000
Contact Now

DHN Disc Fat Milk Centrifuge Separator

Description
Voltage: 220V/380V/400V/440V/460V Power: 15000 W
Dimension: 1800*1200*2030 Mm Weight: 1880 KG
Setting Speed: 6600 Material: 304/316L Stainless Steel
Motor Power: 15 Kw Discharge Type: PLC Control Automatic Discharge
Bearing: SKF Bearing Capacity: 5000-7000, 3000-7000 LPH
Core Components: PLC, Bearing, Motor Centrifugal Type: High Speed Separation
Inlet Pressure: 0.05 Mpa Outlet Pressure: 0.1-0.35 Mpa
Separation Factor: High
Highlight:

fat milk centrifuge separator

,

disc oil separator machine

,

industrial milk fat separator

DHN Disc Fat Milk Centrifuge Separator
The DHN Disc Fat Milk Centrifuge Separator is engineered for the dairy processing industry, designed to continuously separate cream and defatted milk from pure milk while removing impurities and sediments. This advanced system also enables milk standardization based on fat content requirements.
Advanced Separation Technology
Juneng's centrifugal separator features specially designed centripetal pumps and inlet/outlet ports that create a gentle separation environment. This preserves active ingredients in the material, maintaining nutritional value, freshness, and original flavor. The separator effectively removes solid particles as small as 1mm dispersed in suspensions from the liquid phase.
DHN Disc Fat Milk Centrifuge Separator 0
DHN Model Specifications for Dairy Clarification
ModelCapacity (L/H)Inlet PressureOutlet PressureWeightDimension (mm)
DHN3602000-50000.05 Mpa0.1-0.35 Mpa1200 kg1530×1150×1500
DHN4705000-100000.05 Mpa0.1-0.4 Mpa1600 kg1800×1200×1750
DHN55010000-200000.05 Mpa0.1-0.4 Mpa2300 kg1950×1550×1960
DHN61625000-350000.1 Mpa0.3 Mpa3000 kg2185×1728×2082
Dairy Clarification Working Principle
Clarification involves two-phase separation, removing suspended solids from liquids or separating two immiscible liquids with different specific gravities. Materials enter the bowl's core section where strong centrifugal force removes impurities from raw material, producing clean milk.
DHN Disc Fat Milk Centrifuge Separator 1
DHNZ Model Specifications for Dairy Skimming
ModelCapacity (L/H)Inlet PressureOutlet PressureWeightDimension
DHNZ204500-10000.05 Mpa0.1-0.2 Mpa520 kg810×850×1350
DHNZ3601000-30000.05 Mpa0.1-0.2 Mpa1200 kg1530×1150×1500
DHNZ4703000-70000.05 Mpa0.1-0.2 Mpa1600 kg1800×1200×2030
DHNZ5505000-100000.05 Mpa0.1-0.2 Mpa2300 kg1950×1550×1960
Dairy Skimming Working Principle
Dairy skimming performs three-phase separation, simultaneously separating two immiscible liquid phases and a solid phase.
DHN Disc Fat Milk Centrifuge Separator 2
Key Advantages
  • Continuous feeding operation
  • High separation factor efficiency
  • Automatic residue discharging system
  • Hydraulic coupling driving for extended service life
  • PLC system automatic control
Applications
  • Hot and cold milk separation
  • Whey protein separation
  • Buttermilk separation
  • Dairy whey clarification
  • Disinfection of dairy products
  • Casein processing
  • Syrup clarification
  • Vegetable juice clarification
  • Tea drinks, coffee, beer and other liquid clarification
DHN Disc Fat Milk Centrifuge Separator 3DHN Disc Fat Milk Centrifuge Separator 4
Related Products
DHN Disc Fat Milk Centrifuge Separator 5
Small Capacity Disc Separator
DHN Disc Fat Milk Centrifuge Separator 6
Self-cleaning Candle Filter
DHN Disc Fat Milk Centrifuge Separator 7
Decanter Centrifuge
DHN Disc Fat Milk Centrifuge Separator 8
Oil Bleaching Filter System
DHN Disc Fat Milk Centrifuge Separator 9
Disc Separator Whole System
DHN Disc Fat Milk Centrifuge Separator 10
Horizontal Plate Filter
DHN Disc Fat Milk Centrifuge Separator 11
Scraper Centrifuge
DHN Disc Fat Milk Centrifuge Separator 12
Multi-bags Filter
DHN Disc Fat Milk Centrifuge Separator 13
Disc Separator Directly Connected
Manufacturing Process
DHN Disc Fat Milk Centrifuge Separator 14
Separator Process Workshop
DHN Disc Fat Milk Centrifuge Separator 15
Drum Processing
DHN Disc Fat Milk Centrifuge Separator 16
Process Center
DHN Disc Fat Milk Centrifuge Separator 17
Ultrasonic Testing
DHN Disc Fat Milk Centrifuge Separator 18
Dynamic Balancing Test
DHN Disc Fat Milk Centrifuge Separator 19
Assembling
Quality Assurance & Quality Control
  • Material Test Report
  • Magnetic Particle Examination
  • Nondestructive Examination
  • Liquid Penetrant Examination
  • Dynamic Balancing Test
  • Radiographic Examination
Our Service
Pre-Sales Service
  • Inquiry and consulting support
  • Sample testing support
  • Factory viewing arrangements
DHN Disc Fat Milk Centrifuge Separator 20DHN Disc Fat Milk Centrifuge Separator 21
After-Sales Service
  • Machine installation training
  • Machine operation training
  • Overseas engineer service availability
Our company maintains a professional after-sales service technical team. All products include engineer-guided installation, debugging assistance, and operator training until complete mastery. For operational issues, we guarantee two-hour response time and dispatch engineers to resolve problems on-site until customer satisfaction.
DHN Disc Fat Milk Centrifuge Separator 22DHN Disc Fat Milk Centrifuge Separator 23DHN Disc Fat Milk Centrifuge Separator 24
