Product Details:
|
| Product Type: | Fermentation Liquor | Core Components: | PLC, Engine, Bearing, Motor |
|---|---|---|---|
| Voltage: | Customized | Power: | 15000 W |
| Material: | Stainless Steel | Function: | Washing And Separation |
| Capacity: | 1000-1500 L/H | Weight: | 2000 Kg |
| Inlet Pressure: | 0.1-0.2 Mpa | Outlet Pressure: | ≤0.4 Mpa |
| Motor Power: | 15-45 Kw | Outline Dimension: | 1700*1200*1720 - 2380*1730*2060 Mm |
| Treatment Capacity: | 2-15 L/H | Packaging Size: | 123*456*789 Mm |
| Packaging Weight: | 1.2 T | ||
| Highlight: | yeast centrifuge separator machine,disc oil separator for yeast,industrial yeast separator with warranty |
||
| Model | Treatment Capacity (L/H) | Inlet Pressure (Mpa) | Outlet Pressure (Mpa) | Motor Power (Kw) | Weight (Kg) | Outline Dimension (mm) |
|---|---|---|---|---|---|---|
| DHFX211 | 2-5 | 0.1 | ≤0.4 | 15 | 1600 | 1700*1200*1720 |
| DHFX214 | 4-9 | 0.2 | ≤0.4 | 22 | 2300 | 1980*1610*1950 |
| DHFX216 | 6-15 | 0.2 | ≤0.4 | 37 | 3200 | 2100*1730*2060 |
| DHYD616 | 2.5-6 | 0.1 | ≤0.4 | 45 | 3400 | 2380*1730*2060 |
| Specification | Details |
|---|---|
| Size | 123 (L) * 456 (W) * 789 (D) |
| Weight | 1.2 T |
| Packaging Details | The normal package is wooden box (Size: L*W*H). If exporting to European countries, the wooden box will be fumigated. If the container is too tight, we use PE film for packing or accommodate special customer requests. |
