Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity

Certification
China JUNENG MACHINERY (CHINA) CO., LTD. certification
China JUNENG MACHINERY (CHINA) CO., LTD. certification
Customer Reviews
Kedua-dua bunyi pemisahan dan getaran adalah ok, berjalan kadar aliran 11㎥ / h

—— Hossain

The equipment is running normally, the flow rate is ok, thank the engineer.

—— Prakash

* The trainer operate the machine.He did a complete maintance. * No Issue * The trainer did a good job.Thanks.

—— Amro Alropshy

이미 확인 된 모든 구분 기호입니다. 아무런 문제가 없습니다.

—— Kim

Масло не проходит через линию промывки, Качество масла не плохое.

—— Alexander

I'm Online Chat Now

Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity

Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity
Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity

Large Image :  Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity

Product Details:
Place of Origin: Jiangsu, China
Brand Name: Juneng
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: CN¥185,364.12-206,015.38

Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity

Description
Voltage: 380V Or Other Power: 22kw
Dimensions: 1850x1550x2050 Weight: 1880 KG
Setting Speed: 6600RPM Material: Stainless Steel 304
Structure: Disk Stack Operation Type: Automatic Continuous Operation
Model: DHSY470 Treatment Capacity: 4000-7000 L/H
Inlet Pressure: 0.05 Mpa Outlet Pressure: 0.1-0.3 Mpa
Motor Power: 15 Kw Core Components: PLC, Bearing, Motor
Capacity: 2500-7000L/H
Highlight:

Stainless Steel 304 Disc Oil Separator

,

Automatic Continuous Operation Disc Oil Separator

,

4000-7000L/H Capacity Oily Water Centrifugal Separator

Disc Type Waste Oil Water Separator
Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity 0

Globally, waste oil and hogwash oil are increasingly recognized as valuable resources that can be transformed into biodiesel. This approach addresses food safety concerns while generating significant economic benefits.

Juneng has established close collaborations with research institutes and universities to leverage centrifugal separation technology in waste oil purification processes. This technology has been successfully implemented in over thirty projects worldwide.

Product Competitive Advantages
  • High-speed operation with exceptional stability
  • Fully enclosed inlet and outlet system
  • Low noise operation with excellent separation efficiency, high oil recovery rate, fully automatic control, and user-friendly operation
  • Low operational, maintenance, and service costs
Successful Applications
  • Separation of methyl ester, glycerin, catalyst, de-soap, and methanol
  • Methyl washing processes
  • Fatty acids extraction
  • Glycerol desalination
Technical Specifications
Model DHSY470
Treatment Capacity (L/H) 4000-7000
Inlet Pressure (MPa) 0.05
Outlet Pressure (MPa) 0.1-0.3
Motor Power (kW) 15
Manufacturing Process & Quality Control
Production Process
Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity 1
Separator Process Workshop
Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity 2
Drum Processing
Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity 3
Process Center
Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity 4
Ultrasonic Testing
Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity 5
Dynamic Balancing Test
Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity 6
Quality Assurance & Control Tests
  • Material Test Report
  • Magnetic Particle Examination
  • Metallographic Analysis Sampling
  • Liquid Penetrant Examination
  • Over Speed Test
  • Spare Parts Inspection
  • Nondestructive Examination
  • Dynamic Balancing Test
  • Radiographic Examination
  • Performance Test
Comprehensive Service Support
Pre-Sales Services
Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity 7
  • Inquiry and consulting support
  • Sample testing support
  • Factory viewing and inspection
After-Sales Services
Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity 8
  • Comprehensive machine installation training
  • Operator training programs
  • Overseas engineering service support
Professional Technical Support Team
Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity 9

Our company maintains a dedicated professional after-sales service technical team. For all equipment sales, our engineers provide on-site installation guidance, commissioning assistance, and comprehensive operator training until proficiency is achieved.

For any operational issues, we guarantee immediate response within two hours of notification. Our service engineers will remain on-site until all issues are resolved to customer satisfaction.

Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity 10
Packaging & Delivery
Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity 11
Packaging Customized wooden crates
Size Varies by model specifications
Weight 1000kg - 3000kg
Packaging Details Standard wooden box packaging (L*W*H). European exports include fumigated packaging. Alternative packaging options available for tight container spaces or special customer requirements.
Transport Domestic: road transport; Overseas: sea or rail transport
Quality Certifications

Juneng has earned numerous honors and obtained comprehensive certifications including:

  • ASME U (Certificate No.: 38793)
  • ISO 9001:2015 (Certificate No.: CN1299-QC)
  • ISO 14001:2015 (Certificate No.: CN1299-EC)
  • OHSAS 18001:2007 (Certificate No.: CN1299-SC)
  • BV Certification
  • CE Certification
Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity 12 Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity 13 Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity 14 Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity 15
Company Profile: Juneng Group

Juneng Group is a large-scale industrial manufacturer in China, specializing in research, development, and production of industrial filters, separators, centrifuges, and pumps.

As an industry leader with approximately 90% domestic market share across oils & fats, chemical, pharmaceutical, beverage, and petrochemical industries, we are recognized as one of the world's prominent producers and suppliers.

With three production bases totaling 280,000 square meters in Nanjing and Yixing cities, we employ over 1,100 skilled workers and operate more than 2,000 units of advanced production equipment and testing instrumentation.

Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity 16
Jiangsu Juneng Machinery Co., Ltd in Yixing

Specializing in manufacturing disc separators and liquid pumps, we provide customized model recommendations to meet specific application requirements.

Operational Tenets
  • Strategy: Professional dedication to building core competitiveness
  • Market: European quality standards at competitive Chinese pricing
  • Management: Practical, standardized, and continuously improving
  • Service: Honest, responsible, and timely
  • Talent: Merit-based, cooperative, and caring
  • Technology: Technology leadership and innovation
Why Choose Juneng Brand
  • Internationally certified high-quality production chain
  • Direct manufacturer pricing for cost-effectiveness
  • Comprehensive technical support and after-sales service
  • Global exports to over 20 countries with excellent customer feedback
  • Comprehensive one-stop service with customized project feasibility reports
Frequently Asked Questions
Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity 17
Factory Visits

Q: How can we visit your factory?

A: International visitors: Fly to Shanghai airport for our complimentary pickup service. Domestic visitors: Travel to Wuxi station by air or train for our pickup service.

Quality Assurance

Q: How do you ensure product quality?

A: As a state-owned enterprise with over 30 years of experience, we implement strict operational policies, utilize advanced processing machinery for component precision, employ licensed operators, conduct multiple processing stages for parts, use internationally renowned transmission and electrical components, and perform comprehensive testing throughout the production process.

Payment Methods

Q: What payment methods do you accept?

A: We accept most payment methods, primarily T/T and L/C at sight.

Warranty Period

Q: What is your product warranty period?

A: Our standard warranty is 12 months following commissioning.

Company Trustworthiness

Q: How can I trust your company as a new customer?

A: With over 10 years on Alibaba.com as golden suppliers, comprehensive authority certifications including CE, ISO9001, and Alibaba onsite check certification, plus a Trade Assurance Limit of US$42,000 (and growing), we provide substantial assurance of our reliability.

Delivery Terms & Time

Q: What are your shipment terms and delivery times?

A: Delivery times vary by order quantity: typically 20 days for standard orders, 30 days for customized equipment.

Pricing & Discounts

Q: Do you offer discounts?

A: We provide competitive pricing combined with exceptional service to deliver optimal value.

Stainless Steel 304 Disc Oil Separator with Automatic Continuous Operation and 4000-7000L/H Capacity 18
