Biodiesel Disc Oil Separator Machine High Pressure Stable Operation

Biodiesel Disc Oil Separator Machine High Pressure Stable Operation
Biodiesel Disc Oil Separator Machine High Pressure Stable Operation

Large Image :  Biodiesel Disc Oil Separator Machine High Pressure Stable Operation

Product Details:
Place of Origin: Jiangsu China
Brand Name: Juneng
Certification: ISO CE
Model Number: DHYY470
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Packed by international standard fumigation wooden case
Delivery Time: 30 days after order
Payment Terms: L/C, T/T
Supply Ability: 1000 sets per year

Biodiesel Disc Oil Separator Machine High Pressure Stable Operation

Description
Product Alias: Disc Oil Separator Treatment Capacity (L/H): 4000-7000
Voltage: 220V/380V/400V/440V/460V Inlet Pressure (Mpa): 0.05
Outlet Pressure (Mpa): 0.1-0.3 Application: Biodiesel
High Light:

conical disc centrifuge

,

disc bowl centrifuge

Biodiesel Disc Oil Separator Machine High Pressure Stable Operation



Disc Oil Separator Description:



Biodiesel is a clean and renewable energy. It is the reborn fuel and excellent substitute of petroleum diesel.



Biodiesel is made by ester exchange process which raw material bases on plant oil crops, wild plants and engineering microalgae type aquatic plants fats as well as animal fats, food waste oil, etc.



Biodiesel also is a typical “green energy”, so develop the bio-diesel has an important strategic significance in continuable economic development, promote alternative energy, reduce environment pressure and control urban air pollution.



By adopting oil and fat as raw materials, biological diesel oil is achieved through etherification reaction with methanol by adding alkali catalyst. The glycerin produced in the reaction is a subsidiary product.

A common view has been formed globally that waste oil and hogwash oil can be transformed into biological diesel oil. This not only solve the problems related to food safety, but also generates considerable economic benefits. Juneng has carried out close cooperation with relevant institutes and universities to make the centrifugal separation technology play an irreplaceable role in the purification process of waste oil, and the technology has been successfully applied in more than thirty projects at home and abroad.



Disc Oil Separator applications:



1, Separation of methyl ester, glycerin, catalyst, de-soap, methanol



2, Methyl washing



3, Extraction of fatty acids



4, Glycerol desalination



Disc Oil Separator advantage:





good separation, high oil rate,



fully automatic control ,easy to operate.



Low cost of operation, maintenance and serving



Disc Oil Separator Parameters



Model Treatment
capacity (L/H)
Inlet
pressure (Mpa)
Outlet
pressure (Mpa)
Motor
power (Kw)
Weight(Kg) Outline
dimension (mm)
DBSY204 700-2000 0.05 0.1-0.25 4 408 810*850*1350
DHSY360 1000-2500 0.05 0.1-0.25 7.5 1280 1500*1150*1500
DHSY470 4000-7000 0.05 0.1-0.3 15 1880 1800*1200*1800
DHSY550 6000-15000 0.05 0.1-0.3 22 2200 1850*1550*2050
DHSY700 8000-25000 0.05 0.1-0.3 37 3300 2050*1700*2300





FAQ


1) Q: How can we visit your factory?


A: If you come from abroad, air to shanghai airport, then we can pick you up at airport.
If you come from domestic city, air or train directly to Wuxi station. We will pick you up at railway station.

2) Q: What payment methods your company accept?



A: We accept most of the payment methods , but mainly accept T/T, L/C at sight .

3) Q: How long is the warranty time for your products?



A: Our officially promised warranty time is 12 months after commissioning .
