|Place of Origin:||Jiangsu China|
|Certification:||CE, ISO9001, ASME|
|Minimum Order Quantity:||1 set|
|Price:||USD 1000-200000 per set|
|Packaging Details:||Internation plywood case and container|
|Delivery Time:||20 days after order|
|Payment Terms:||L/C, T/T|
|Supply Ability:||2000 sets per year|
|Product Alias:||NYB High Efficiency Plate Type Hermetic Filter||Discharge:||Automatic By Vibration|
|Material:||Carbon Steel||Filtration Area:||From 2 M2 To 100 M2|
|Function:||Purify The Liquid||Structure:||Leaf Filter|
|Color:||Green, Blue Or Customised||Design:||4bar Or Customised|
Carbon Steel Vertical Pressure Leaf Filters For Chemical / Pharmaceutical Industry
The main body of the filter is made up of vessel, filter gauzes, lifting structure and automatic discharging device. Filter gauzes are made by material of multilyer stainess steel which installed at the center liquid pipe and cleaned up conveniently .
In the process of filtration, the unfiltered liquid with filter aid come into the body through transmission system. After a stable filter cake formed on the filter gauze flakes, the filtrate are filtered through the micropores of filter cake
Filter model list
|Vertical Leaf Pressure Filter||NYB-2,NYB-7,NYB-20...NYB-90|
|Self-cleaning Candle Filter||ZX-5,ZX-10,ZX-20...ZX-100|
|Horizontal Leaf Pressure Filter||WYB-5,WYB-30,WYB-60...WYB-200|
NYB High Efficiency Plate Type leaf Filter is a high-efficient, energy-saving and Hermetically operated fine filter equipmetn. It is widely used in chemical, petroleum, painting, foodstiff,pharmaceutical and many other industries.
Since this equipmetn has many advantages such as unique structure, compact volunme, high filter efficiency, fineness of filtered liquor, no material wastage, without consumption of filter paper , filter cloth. It's only consuming small quantity of filter aid. It can be conveniently maintained , cleaned and operated at very low cost.
The Filter is composed of shell, filtration plate , cover, and automatic vibration device. Amont them, the filtration plate is made of many layers of stainless steel filtration materials, and they are installed on the central liquid collection pipe. So it can be dismantled for cleaning very conveniently.
Application of High Efficiency Plate Type Leaf filter:
1. Oil industry :Crude oil, bleached oil, hydrided oil, radonized oil, stearin, fatty acid, etc.
2. Petroleum chemical products: diesel oil, lubricating oil, paraffin wax, mineral oil, etc.
3. Beverage: Beer, Juice, Wine, Milk, etc.
4. Organic chemical prodccts:various organic aid, alcohol, benzene, aldehyde, etc.
5. Paint: Resin, vanish, dye, lacquer,etc.
6. Inorganic chemical products : bromine water, potassim cyanide, fluorite, etc.
7. Foodstuff: gelatin, vinegar, starch, syrup, sugar water, etc.
8. Pharmaceutical products: Hydrogen peroxide solution, vitamin, etc.
9. Mineral products: fine coal, cinder, etc.
10 Others; air, depuration of water, etc.
Used on site :
During selection process :
1. Professional Engineer wil recommend you the most suitable model according to your requirement.
2. Supply reference process flow chart .
3. Supply on-site installation and operation test
4. Integration for control system and process
5. Customized size and structure
After service :
1. Months guarantee period from machine arriving date.
2. Sufficient spare parts in stock are available .
3. Technicians are availabled for overseas service.
4. 24 hours technical consultation .
5. The customer could get trained by our experienced tecnician.
6. Routine tracing will be done timely.
7. Guide you do the normal maintenance.
8. Suggestions and any comments &reflection from customer would be treated in priority.
9. Markting team will visiting if you need.
