Product Details:
|
| Other Name: | Horizontal Plate Type Filter | Work Pressure: | 0.4 MPa |
|---|---|---|---|
| Work Temperature: | 150 ℃ | Warrenty: | 12 Months |
| Application: | Chemicals, Petroleum, Foodstuff And Pharmacy | Feature: | Energy Saving, Auto-hermetic |
| High Light: | plate type filter,horizontal plate filter |
||
Stainless Steel 0.4Mpa Horizontal Pressure Leaf Filter Used Syrups / Dewaxing / Degrease
Product competitive advantage:
1, Filtering gauze flakes can be pulled out automatically, and easy to be inspected and cleaned.
2, As the leaves filtering on both sides, large filtration area and solids holding capacity can be obtained.
3, Automatically residue discharging by which labor can be largely reduced.
4, Controlled by hydraulic thus automation is to be.
5, A large filtration area and large solids holding capacity can be obtained .
Product description:
This product is of novel design, the main body of filter consists of filtration tank, screen, end-plate pullout device, automatic dreg discharging device, etc.
During filtering, the filter aid is mixed up with material in the mixing cylinder then transmitted by pump onto the filter screen to form a filter cake layer.
Once the stable filter cake is realized, the minute filter aid particles provide countless micro passages, which entrap the suspended impurity and let the clear liquid through.
Therefore the real filtration is realized through the cake layer. In case that the filter cake over the surface of filter screen reaches certain thickness, the feeding shall be stopped, and compressed air or steam shall be employed to blow dry the cake,
and clean the filter screen the discharge , the vibration dreg discharging device shall be switched on, the dregs shall be unloaded because of weight and vibration. As to sticky filter cake, manual help shall be provided to clean up the dregs.
Application:
Food industry : Syrups, edible oils, dewaxing , decolour, degrease
Chemical industries: Sulphur, aluminum sulfate, Polyaluminum chloride, plastic, dyestuff intermediate, bleaching liquid, lubricant additives and intermediate and high pressure polyethylene, etc.
Introduction of Company:
Juneng Group has set-up a 1st class in-house laboratory for chemical composition analysis, metallographic analysis, spectrum analysis, performance analysis, radiographic inspection, magnetism inspection, ultra-sonic inspection and etc.
This is to imply with the latest advance instrumentations and rigorous working attitude to ensure every part of product is stable and reliable.
Technonlgical Parameters:
| Area ㎡ | Shell Diametre ㎜ | Work Pressure MPa | Work Temperature℃ | Proximate Treatment Capacity(T/h.㎡) | |
| 5,10,15,20,25,30 | 900,1200 | 0.4 | 150 | Oil | 0.2 |
| 35,40,45,50,60... | 1400,1500... | 0.4 | 150 | Drinks | 0.8 |
