Product Details:
|
Processing: | 3 Phase Decanter Centrifuge | Control: | Controlled By Cabinet |
---|---|---|---|
After-sales Service Provided: | On-site Guidance Of Installation | Material Of Drum: | Stainless Steel |
Application: | Cow Dung Treatment | Feature: | High Efficiency, Ecofriendly |
Description:
Centrifugal sedimentation is the working principle of this centrifuge, it can separate two phases (suspended solid liquid and liquid), solid phase is pushed out by spiral continually; this equipment is a constant and high effective equipment which used in separating solid-liquid.
It has a wide range application , it has a good applicability for many material and can be widely used in chemical industry, light industry, food, paper, mining and other industrial sectors. It applies to carry out separating liquid and solid of the suspensions material which weight thickness of solid phase ≤ 10% (or volume concentration of ≤ 50% after settlement24 hours) and equivalent diameter of solid-phase particle ≥ 0.005 ~ 2 mm, liquid-solid density difference ≥ 0.05 g / cm 3, such as calcium carbonate, calcium sulfate, polyvinyl chloride, lees, bean dregs , soy protein, paper pulp, vegetable oil and palm oil, kaolin, white mud, sludge from environmental protection industry and also applies to various types of chemical products which use settlement centrifugal separation principle, these material all can be carried out effectively.
Advantages :
1. Lower cake transportation costs due to very dry solids
2. Better recovery of nutrients due to very high separation efficiency
3. Lower fresh water consumption compared to other processes
4. Long service life
5. 24 h operating reliability
6. Optimum wear protection
7. Energy saving design
8. Easy to operate and maitain
9. Low maintain cost
10. Competive price for spare parts
Features
Technological Parameters:
Model | Drum diameter mm | Inlet liquid capacity㎥/h | Power of main/auxiliary motor Kw | Weight Kg | Dimension (max) mm |
LW250 | 250 | 1-4 | 11/4 | 1200 | 2650*720*900 |
LW(F)250 | 250 | 1-4 | 11/4 | 1200 | 2650*720*900 |
LW250(W) | 250 | 1~5 | 11/4 | 1300 | 2750*720*900 |
LW350 | 350 | 5~15 | 22/5.5 | 2000 | 3585*980*1238 |
LW(F)350 | 350 | 5~15 | 22/5.5 | 2000 | 3585*980*1238 |
LW350(W) | 350 | 5~18 | 15/5.5 | 2200 | 3412*1090*950 |
LW(S)350 | 350 | 2~10 | 22/5.5 | 2000 | 3676*980*1238 |
LW450 | 450 | 5~20 | 30/11 | 3000 | 4380*1080*1360 |
LW(F)450 | 450 | 5~20 | 30/11 | 3000 | 4380*1080*1360 |
LW450(W) | 450 | 5~28 | 30/11 | 3200 | 4380*1080*1360 |
LW(S)450 | 450 | 5~15 | 37/11 | 3200 | 4195*1080*1360 |
*** F: Ex-proof, W:Waste water, S: Three phase FS:Ex-- proof and three phase
