Product Details:
|
| Processing: | 3 Phase Decanter Centrifuge | Control: | Control Panel |
|---|---|---|---|
| After-sales Service Provided: | Online Support | Material: | Stainless Steel |
| Application: | Dehydration Offish Meal And Fish | Feature: | High Efficiency, Ecofriendly |
| High Light: | continuous horizontal centrifuge,sludge decanter centrifuge |
||
Applications
The 3-phase decanter separates which contains oil into an oil phase, solids and virtually oilfree waste water. Because of its high dry matter, the solids can be recycled relatively easily.
In addition, the solids concentration in the waste water is lower than would be the case if nozzle separators are used in conventional process.
Advantages :
1. Lower cake transportation costs due to very dry solids
2. Better recovery of nutrients due to very high separation efficiency
3. Lower fresh water consumption compared to other processes
4. Long service life
5. 24 h operating reliability
6. Optimum wear protection
7. Energy saving design
8. Easy to operate and maitain
9. Low maintain cost
10. Competive price for spare parts
Features
Technological Parameters:
| Model | Drum diameter mm | Inlet liquid capacity㎥/h | Power of main/auxiliary motor Kw | Weight Kg | Dimension (max) mm |
| LW250 | 250 | 1-4 | 11/4 | 1200 | 2650*720*900 |
| LW(F)250 | 250 | 1-4 | 11/4 | 1200 | 2650*720*900 |
| LW250(W) | 250 | 1~5 | 11/4 | 1300 | 2750*720*900 |
| LW350 | 350 | 5~15 | 22/5.5 | 2000 | 3585*980*1238 |
| LW(F)350 | 350 | 5~15 | 22/5.5 | 2000 | 3585*980*1238 |
| LW350(W) | 350 | 5~18 | 15/5.5 | 2200 | 3412*1090*950 |
| LW(S)350 | 350 | 2~10 | 22/5.5 | 2000 | 3676*980*1238 |
| LW450 | 450 | 5~20 | 30/11 | 3000 | 4380*1080*1360 |
| LW(F)450 | 450 | 5~20 | 30/11 | 3000 | 4380*1080*1360 |
| LW450(W) | 450 | 5~28 | 30/11 | 3200 | 4380*1080*1360 |
| LW(S)450 | 450 | 5~15 | 37/11 | 3200 | 4195*1080*1360 |
*** F: Ex-proof, W:Waste water, S: Three phase FS:Ex-- proof and three phase
