High Efficiency Industrial Bag Filters For Paint , Beer , Vegetable Oil

High Efficiency Industrial Bag Filters For Paint , Beer , Vegetable Oil
High Efficiency Industrial Bag Filters For Paint , Beer , Vegetable Oil High Efficiency Industrial Bag Filters For Paint , Beer , Vegetable Oil

Large Image :  High Efficiency Industrial Bag Filters For Paint , Beer , Vegetable Oil

Product Details:
Place of Origin: China(Yixing, Jiangsu)
Brand Name: Juneng Machinery
Certification: CE、 ASME U、ISO9001
Model Number: DL-1P2S
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: Standard Wooden Case
Delivery Time: 10 days
Payment Terms: TT
Supply Ability: 40 set / months

High Efficiency Industrial Bag Filters For Paint , Beer , Vegetable Oil

Description
Name: Industrial Bag Filters Nominal Filtration Precision: 5 μm
Application: Paint , Beer , Vegetable Oil Feature: High Efficiency
Max Flowrate: 20 ㎥/h Warrenty: 12 Months
High Light:

duplex bag filter

,

stainless steel bag filter

High Efficiency Industrial Bag Filters For Paint , Beer , Vegetable Oil



Industrial Bag Filters Introduction


Filter body is mainly composed of three parts:the filter container,supporting basket and the filter bag,filter process.
Replace or clean the filter bag,just loosen the ring bolt,rotating the hand-wheel lifting cover,can be removed.
Multi bag filter has the characteristics of large capacity,large amount of contamination,obvious filtration effect,simple poeration,low cost operation.



Industrial Bag Filters Description:



DL series bag filter is a multifunction filter equipment with new structure, small occupancy, flexible operation, energy-saving, high-efficiency, enclosed operation and excellent applicability.

DL series filter bag is mainly composed by filter cylinder, cylinder lid, quick-opening structure, filter bag reinforce net.

DL series filter bag belongs to pressure filter equipment , liquid flow into the filter bag through the side-way. Filter bag itself is fitted in the reinforce net that the qualified filtrate is achieved after the liquid pass the filter bag which has various precision ranks.



The impurity is seized by the filter bag. The filter bag is easy to be changed and has little consumption of materials.



High Efficiency Industrial Bag Filters For Paint , Beer , Vegetable Oil 0


Industrial Bag Filters Applications:



It’s widely used in paint, beer, vegetable oil, pharmaceutical, cosmetic, chemicals, petroleum products, textile chemicals, sensitization chemical, electroplate, milk, mineral water, hot solvent, milk rubber, industrial water, sweet water, resin, printing ink, industrial waste water, juice, edible oil, etc.





Industrial Bag Filters Specifications:





Model Filtration area ㎡ Inlet/outlet caliber mm Max flowrate ㎥/h Max work pressure Mpa Max temperature ℃ Nominal filtration precision μm
DL-1P1S 0.25 DN40 10 0.4 120The working temperature is related to the material of filter bag . 1,5,10,15,25,40,50,65,75,80,100……1200
DL-1P2S 0.5 DN40 20
DL-4P2S 2 DN80 80
DL-8P2S 4 DN125 160
DL32P2S 16 DN200 640





Introduction of Company:



Juneng Group is a large scale manufacturer of industrial products in China with its subsidiaries namely Juneng Machinery(China) Co., Ltd and Jiangsu Juneng Machinery Co., Ltd.



The group principally engaged with the in-house research & development as well as manufacturing of various industrial filters, separators and pumps.



The Company is proud to be the leader in such industry with Fats industry, Chemical industry, Pharmaceutical industry, Beverage industry, Petrol - chemical industry, and now is one of the well-know producers and suppliers in the world.



The company now has its three production bases with a total capacity of 280,000 square meters in Nanjing City and Yixing City of Jiangsu province, permanent workforces not less than 1300 people and the production line is well equipped with more than 1500 units of advanced production equipment and test instrumentation.
