Product Details:
|
| Product Alias: | DLJ | Material Of Filter Bag: | Polyester |
|---|---|---|---|
| Application: | Edible Oil And Wax | Feature: | Optional Filter Precision |
| Filtration Area: | 0.25 ㎡ | Max Work Pressure: | 0.4 Mpa |
| High Light: | duplex bag filter,multi bag filter |
||
Stainless Steel Bag Type Filter , Vegetable Oil Filter Food Standard
Product Description:
DL series bag filter is one of the pressure filter equipment , liquid flow into the filter bag through the side-way. Filter bag itself is fitted in the reinforce net that the qualified filtrate is achieved after the liquid pass the filter bag which has various precision ranks.
DL bag-type filters are a kind of all purpose filter equipment with original structure, small volume, easy and agile operation, energy conservation, high efficiency, leak-free working mode and strong adaptability.
DL series bag filter is mainly composed of filter cylinder, cylinder lid, quick-opening structure, filter bag reinforce net.
The solid impurity is seized by the filter bag. The filter bag with various materials is easy to be changed and has little consumption of treating materials.
Product Applications:
It’s widely used in paint, beer, vegetable oil, medicine, cosmetic, petroleum product, chemical textile, light sensitive chemical, electroplate liquid, milk, mineral water, hot solvent, emulsion, industrial water, sweet water, resin, printing ink, industrial wastewater, fruit juice, edible oil and wax and so on.
Product competitive advantage:
1. Small occupancy,
2. High-efficiency,
3. Enclosed operation,
4. Excellent applicability,
5. Easy changed filter bag.
Wearing parts list
Model | O-ring(External diameter ×wire diameter × number) |
Main seal gasket (1 set) (Thickness X Width X nominal diameter) |
| DL (T)-1P | Ø240×5.7×1 Ø195×5.7×2 | / |
| DL-1P | Ø210×5.7×1 Ø195×5.7×1 Ø80×5.7×1 | / |
| DL-4P | Ø210×5.7×4 Ø195×5.7×4 | 6×12×600 |
| DL-6P | Ø210×5.7×6 Ø195×5.7×6 | 6×12×800 |
| DL-8P | Ø210×5.7×8 Ø195×5.7×8 | 6×12×900 |
| DL-10P | Ø210×5.7×10 Ø195×5.7×10 | 10×14×1000 |
| DL-12P | Ø210×5.7×12 Ø195×5.7×12 | 10×14×1200 |
| DL-16P | Ø210×5.7×16 Ø195×5.7×16 | 10×14×1300 |
| DL-20P | Ø210×5.7×20 Ø195×5.7×20 | 10×14×1400 |
Company detail
Juneng Group is a large scale manufacturer of industrial products in China. This group principally engaged with the in-house research & development as well as manufacturing of various industrial filters, separators , centrifuges and pumps.
Why Choose Juneng brand
1. One-top service, customised Exclusive project feasibility report .
2. International High quality Certification production chain.
3. Exports to more than 20 countries and regions, good customers feedback.
Product Specifications:
| Model | Filtration area ㎡ | Inlet/outlet caliber mm | Max flowrate ㎥/h | Max work pressure Mpa | Max temperature ℃ | Nominal filtration precision μm |
| DL-1P1S | 0.25 | DN40 | 10 | 0.4 | 120 | 1,5,10,15,25,40,50,65,75,80,100……1200 |
| DL-1P2S | 0.5 | DN40 | 20 | |||
| DL-4P1S | 1 | DN80 | 40 | |||
| DL-4P2S | 2 | DN80 | 80 |
FAQ:
1 ) Q: Do you give any Discount?
A: I will surely try my best to help you get those by the best price and good service at the same time.
2) Q: How do you ensure the quality of your products?
A: Our Company is a state owned enterprise with more than 30 years experience , strict operation policy is performed, advanced processing machines guarangtee the precision of all components,
workers with operation license, parts get multiprocessing, transmission& electrical parts are of international famous brand. Series of test and inspection are done in the whole producing state.
3) Q: I haven ' t done business with you company before, how can I trust your company ?
A: Our company has been in Alibaba.com for 10 years, which is longer than most of our fellow suppliers, we have been golden suppliers for years.
What ' s more, we have got quite a lot authority certificates, for example, CE, ISO9001, Alibaba onsite check certificate. I hope those above will be persuasive enough.
Our Trade Assurance Limit is US$ 42,000,and it will still going up.
