Product Details:
|
| Product Alias: | Vertical Leaf Filter | Feature: | High Efficiency, Easy Cleaning |
|---|---|---|---|
| Inlet & Outlet Connection: | Flange | Motor Model: | YB112M-6/YB801-4 |
| Motor Power: | 2.2/0.55 Kw | Weight: | 1800 Kg |
| High Light: | horizontal plate pressure filter,vertical plate filter |
||
Filter Screen / Filter Mesh Pressure Leaf Filter Vertical Pressure Leaf Filters for Oil industry
Application:
Oil industry: crude oil , bleached oil, hydrided oil, radonized oil, stearin, fatty acid, etc.(such as soybean oil, rap seed oil, palm oil)
Petrochemical products: diesel oil, lubricating oil, paraffin and mineral moil products
Organic chemical products: various organic acid, ester, benzene and aldehyde
Oil paint: resin, varnish, dye and lacquer
Company Service:
We sincerely offer various fittings for import and domestic separator users. Our professional personnel will give you help and consultation at any time.
Repair and Maintenance:
We sincerely offer various fittings for import and domestic separator users. Our professional personnel will give you help and consultation at any time.
Training:
Juneng Company provides parts and repair, maintenance as well as techical advice for the demestic and import separator in long time. We guarantee the quality of every maintenance and service.
Product Specifications:
| Model | Shell diameter | Space between filter leaf | Inlet/outlet caliber | Overflow port | Discharge port | Height | Floor Spare |
| NYB-2 | ∅400 | 50 | DN25 | DN25 | DN150 | 1550 | 620×600 |
| NYB-4 | ∅500 | 50 | DN40 | DN25 | DN200 | 1800 | 770×740 |
| NYB-7 | ∅600 | 50 | DN40 | DN25 | DN250 | 2200 | 1310×1000 |
| NYB-10 | ∅800 | 70 | DN50 | DN25 | DN300 | 2400 | 1510×1060 |
| NYB-12 | ∅900 | 70 | DN50 | DN40 | DN400 | 2500 | 1610×1250 |
| NYB-15 | ∅1000 | 70 | DN50 | DN40 | DN400 | 2650 | 1710×1350 |
| NYB-20 | ∅1000 | 70 | DN50 | DN40 | DN400 | 2950 | 1710×1350 |
| NYB-25 | ∅1100 | 70 | DN50 | DN40 | DN500 | 3020 | 1810×1430 |
| NYB-30 | ∅1200 | 70 | DN50 | DN40 | DN500 | 3150 | 2030×1550 |
| NYB-36 | ∅1200 | 70 | DN65 | DN50 | DN500 | 3250 | 2030×1550 |
| NYB-40 | ∅1300 | 70 | DN65 | DN50 | DN600 | 3350 | 2130×1560 |
| NYB-45 | ∅1300 | 70 | DN65 | DN50 | DN600 | 3550 | 2130×1560 |
| NYB-52 | ∅1400 | 75 | DN80 | DN50 | DN600 | 3670 | 2230×1650 |
| NYB-60 | ∅1500 | 75 | DN80 | DN50 | DN600 | 3810 | 2310×1750 |
| NYB-70 | ∅1600 | 80 | DN80 | DN50 | DN600 | 4500 | 3050×1950 |
| NYB-80 | ∅1750 | 80 | DN80 | DN50 | DN600 | 4500 | 3210×2100 |
| NYB-90 | ∅1850 | 80 | DN80 | DN50 | DN600 | 4650 | 3300×2200 |
Product description:
This model is a combination structure. The customer use it directly when the machine arrive to plant .
NYB high efficiency plate hermetic filter is a high-efficient, energy-saving and hermetically operated fine filter equipment. It is widely used in chemical, petroleum, painting, foodstuff, pharmaceutical and many other industries.
The filter is composed of shell, filtration plate, cover, and automatic dump device.
Among them, the filtration plate is made of many layers of stainless steel filtration
materials, and they re installed on the central liquid collection pipe,
so it can be dismantled for cleaning very conveniently.
FAQ:
1. Q: What payment methods your company accept?
A: We accept most of the payment methods , but mainly accept T/T, L/C at sight .
2. Q: How long is the warranty time for your products?
A: Our officially promised warranty time is 12 months after commissioning .
3. Q: What ' s the shipment terms and delivery time of your company?
A: Well, the delivery time depend on the quantity of your order. Usually is 20 days . For some customized machine 30 days is necessary.
4. Q: Do you give any Discount?
A: I will surely try my best to help you get those by the best price and good service at the same time.
